Ladder Access Roof Hatch Type CS-50TB Product Image
Companionway Access Roof Hatch
CS-50TB 760x1500mm

The CS-50TB Roof Access Hatch is ideal for installations where frequent access to the roof area is required. At 760mm x 1500mm, the CS-50TB allows easier movement of maintenance personnel, tools and equipment to and from the roof (Patent pending).

BILCO Roof Access Hatches feature a thermally broken frame and cover design that minimizes heat transfer between interior and exterior metal surfaces. The result is a product that resists harmful condensation and provides superior energy efficiency. Products are tested and approved to BS EN standards for weathertightness, sound rating, and security.

Illustration showing a man climbing a ladder hatch to access the roof area

CS-50TB

Features / Benefits

Thermally broken cover and frame design provide superior thermal performance.

Engineered with compression spring operators to provide smooth, easy, one-hand operation, regardless of size. BILCO Roof Access Hatches meet the requirements of Manual Handling Regulations.

Automatic hold-open arm locks the cover in the open position to ensure safe egress. Grip handle allows for easy, one-hand release and closing.

Overlapping cover design, fully welded corners on cover and curb, closed-cell EPDM rubber gasket, and fully insulated cover and curb ensure weathertightness and energy efficiency.

Constructed with corrosion-resistant materials to provide many years of trouble-free, dependable service.

Heavy gauge construction and positive latching mechanism maintain building security.

Curb features the Bil-Clip® Flashing System, an innovative method to quickly and easily secure single-ply roofing material to BILCO roof products.

Performance Standards CS-50TB

U-VALUE 0.278 W/m²K (homogeneous)
1.39 W/m²K (Developed Area)
BS EN 12207:2000 Air Permeability 4.83 m³/hour/m² at 600Pa
BS EN 12208:2000 Water Tightness Class 9A
BS EN 12210:2000 Wind Resistance Class E2400
BS EN 1991-1 Snow Load 1200Pa for 1 hour
BS 8200 Impact Resistance Pass
BS EN ISO 140 Acoustic 25dB
BS EN 1627-1630 Security Pass
Wind Speed With Open Cover 30 m/s
companionway access roof hatch at ironmonger row

Downloads CS-50TB

Specification (.doc)

External Resources / Links

BIM Objects

Guide Specification CS-50TB

MATERIALCover and frame are 2.3mm Aluminium
CoverBrake-formed, hollow-metal design with 75mm concealed polyisocyanurate insulation, 127mm beaded overlapping flange, fully welded at corners, and internally reinforced for 195 kg/m² live load.
Curb305mm in height with integral capflashing, 75mm polyisocyanurate insulation, fully welded at corners, and 140mm mounting flange with 11mm holes provided for securing frame to the roof deck.
GASKETExtruded EPDM rubber gasket permanently adhered to cover. Air leakage performance 4.83m³/hr/m² @ 600Pa Tested to BS EN 12207: 2000
HINGESHeavy-duty pintle hinges with 9.5mm Stainless Steel Type 316 hinge pins.
LatchSlam latch with interior and exterior turn handles and padlock hasps.
Lift AssistanceCompression spring operators enclosed in telescopic tubes. Automatic hold-open arm with grip handle release.
FinishMill finish Aluminium
HARDWAREEngineered composite compression spring tubes with steel compression springs packed in grease. Stainless Steel Type 316 hinges. All other hardware is zinc plated/chromate sealed.
NotesNational Physical Laboratory U-Value test report available upon request. Patent pending.
